P/N | Model | Measurement Range | Accuracy | Resolution | Interface | Type | Frequency Response |
8000-1034-060 | PT-HD 60/30/52 | Zrange =60 mm, Xrange =22 mm | 0.025% FSR | Zresolution=2?m | Ethernet | RED Laser, 2M Laser Class | 6kHz |
8000-1035-060 | PT-HD 60/30/52 | Zrange =60 mm, Xrange =22 mm | 0.025% FSR | Zresolution=2?m | Ethernet | BLUE Laser, 2M Laser Class | 6kHz |
8000-1036-060 | PT-HD 60/30/52 | Zrange =60 mm, Xrange =22 mm | 0.025% FSR | Zresolution=2?m | Ethernet | RED Laser, 3R Laser Class | 6kHz |
8000-1037-060 | PT-HD 60/30/52 | Zrange =60 mm, Xrange =22 mm | 0.025% FSR | Zresolution=2?m | Ethernet | BLUE Laser, 3R Laser Class | 6kHz |
8000-1039-060 | PT-HD 60/30/52 | Zrange =60 mm, Xrange =22 mm | 0.025% FSR | Zresolution=2?m | Ethernet | BLUE Laser, 3B Laser Class | 6kHz |
8000-1034-130 | PT-HD 130/50/110 | Zrange =130 mm, Xrange =60 mm | 0.025% FSR | Zresolution= 3.2?m | Ethernet | RED Laser, 2M Laser Class | 6kHz |
8000-1035-130 | PT-HD 130/50/110 | Zrange =130 mm, Xrange =60 mm | 0.025% FSR | Zresolution= 3.2?m | Ethernet | BLUE Laser, 2M Laser Class | 6kHz |
8000-1036-130 | PT-HD 130/50/110 | Zrange =130 mm, Xrange =60 mm | 0.025% FSR | Zresolution= 3.2?m | Ethernet | RED Laser, 3R Laser Class | 6kHz |
8000-1037-130 | PT-HD 130/50/110 | Zrange =130 mm, Xrange =60 mm | 0.025% FSR | Zresolution= 3.2?m | Ethernet | BLUE Laser, 3R Laser Class | 6kHz |
8000-1039-130 | PT-HD 130/50/110 | Zrange =130 mm, Xrange =60 mm | 0.025% FSR | Zresolution= 3.2?m | Ethernet | BLUE Laser, 3B Laser Class | 6kHz |
8000-1034-260 | PT-HD 260/150/230 | Zrange =260 mm, Xrange =80 mm | 0.025% FSR | Zresolution=9.6?m | Ethernet | RED Laser, 2M Laser Class | 6kHz |
8000-1035-260 | PT-HD 260/150/230 | Zrange =260 mm, Xrange =80 mm | 0.025% FSR | Zresolution=9.6?m | Ethernet | BLUE Laser,2M Laser Class | 6kHz |
8000-1036-260 | PT-HD 260/150/230 | Zrange =260 mm, Xrange =80 mm | 0.025% FSR | Zresolution=9.6?m | Ethernet | RED Laser, 3R Laser Class | 6kHz |
8000-1037-260 | PT-HD 260/150/230 | Zrange =260 mm, Xrange =80 mm | 0.025% FSR | Zresolution=9.6?m | Ethernet | BLUE Laser, 3R Laser Class | 6kHz |
8000-1039-260 | PT-HD 260/150/230 | Zrange =260 mm, Xrange =80 mm | 0.025% FSR | Zresolution=9.6?m | Ethernet | BLUE Laser, 3B Laser Class | 6kHz |
8000-1034-520 | PT-HD 520/290/445 | Zrange =520 mm, Xrange =165 mm | 0.025% FSR | Zresolution=17.8?m | Ethernet | RED Laser, 2M Laser Class | 6kHz |
8000-1035-520 | PT-HD 520/290/445 | Zrange =520 mm, Xrange =165 mm | 0.025% FSR | Zresolution=17.8?m | Ethernet | BLUE Laser,2M Laser Class | 6kHz |
8000-1036-520 | PT-HD 520/290/445 | Zrange =520 mm, Xrange =165 mm | 0.025% FSR | Zresolution=17.8?m | Ethernet | RED Laser, 3R Laser Class | 6kHz |
8000-1037-520 | PT-HD 520/290/445 | Zrange =520 mm, Xrange =165 mm | 0.025% FSR | Zresolution=17.8?m | Ethernet | BLUE Laser, 3R Laser Class | 6kHz |
8000-1039-520 | PT-HD 520/290/445 | Zrange =520 mm, Xrange =165 mm | 0.025% FSR | Zresolution=17.8?m | Ethernet | BLUE Laser, 3B Laser Class | 6kHz |
8000-1034-800 | PT-HD 800/450/720 | Zrange =800 mm, Xrange =270 mm | 0.025% FSR | Zresolution=28?m | Ethernet | RED Laser, 2M Laser Class | 6kHz |
8000-1035-800 | PT-HD 800/450/720 | Zrange =800 mm, Xrange =270 mm | 0.025% FSR | Zresolution=28?m | Ethernet | BLUE Laser, 2M Laser Class | 6kHz |
8000-1036-800 | PT-HD 800/450/720 | Zrange =800 mm, Xrange =270 mm | 0.025% FSR | Zresolution=28?m | Ethernet | RED Laser, 3R Laser Class | 6kHz |
8000-1037-800 | PT-HD 800/450/720 | Zrange =800 mm, Xrange =270 mm | 0.025% FSR | Zresolution=28?m | Ethernet | BLUE Laser, 3R Laser Class | 6kHz |
8000-1039-800 | PT-HD 800/450/720 | Zrange =800 mm, Xrange =270 mm | 0.025% FSR | Zresolution=28?m | Ethernet | BLUE Laser, 3B Laser Class | 6kHz |
